SHIPLAP
SHIPLAP
Perfect lines as far as the eye can see. Our Shiplap boards are profiled to produce an overlap, which allows for a continuous cladding look and uninterrupted, clean lines. Shiplap timber cladding provides a modern and clean cedar finish that adds a touch of cladding class to any internal or external shiplap application. Modinex timber lining boards can be used in both vertical and horizontal applications; including timber ceiling lining boards and cedar wall lining panels
Step 1: Select Size
82x9mm
133x9mm
82x12mm
133x12mm
82x15mm
133x15mm
82x18mm
133x18mm
181x18mm
Step 2: Select Materials
Western Red Cedar
Step 3: Select Colours
Western Red Cedar
Step 4: Start Building Your Design
How to Install – Exterior Timber Cladding
How to Install – Interior Timber Cladding
Features and Benefits
All Modinex Group products deliver a superior look and feel, and a low maintenance approach - the perfect solution.
Sustainable Timbers
Sustainably-harvested timber PEFC™ Certified
Insulation
Excellent insulation and acoustic
Weather Protection
Overlap profile has machined drip grooves for superior weather protection
Diverse Look
Can be painted or stained. Available in Dressed face and Bandsawn face
Size & Specifications
| Profile Code | Cover | Thickness (mm) | Profile Height(mm) | Profile Length (mm) | Profile Width(mm) |
|---|---|---|---|---|---|
| PR-SLI-WRC-82X9 | 82mm | 9mm | Max Span 450mm | Random Lengths 900mm to 6000mm | 92mm |
| PR-SLI-WRC-133X9 | 133mm | 9mm | Max Span 450mm | Random Lengths 900mm to 6000mm | 143mm |
| PR-SLS-WRC-82X12 | 82mm | 12mm | Max Span 600mm | Random Lengths 900mm to 6000mm | 92mm |
| PR-SLS-WRC-133X12 | 133mm | 12mm | Max Span 600mm | Random Lengths 900mm to 6000mm | 143mm |
| PR-SLM-WRC-82X15 | 82mm | 15mm | Max Span 600mm | Random Lengths 900mm to 6000mm | 92mm |
| PR-SLM-WRC-133X15 | 133mm | 15mm | Max Span 600mm | Random Lengths 900mm to 6000mm | 143mm |
| PR-SLE-WRC-82X18 | 82mm | 18mm | Max Span 600mm | Random Lengths 900mm to 6000mm | 92mm |
| PR-SLE-WRC-133X18 | 133mm | 18mm | Max Span 600mm | Random Lengths 900mm to 6000mm | 143mm |
| PR-SLE-WRC-181X18 | 181mm | 18mm | Max Span 600mm | Random Lengths 900mm to 6000mm | 191mm |
