AUSTRATUS GRID – ALUMINIUM
https://www.modinex.com.au/wp-content/uploads/2024/07/Factsheet-Austratus-Grid-Aluminium_AUG2025.pdf
https://www.modinex.com.au/wp-content/uploads/2024/08/Austratus-Installation-Guide-Jun26.pdf
https://www.modinex.com.au/wp-content/uploads/2023/11/238-George-Street-Brisbane-e1717999083476.jpg
Austratus Grid - Aluminium
A compliant suspended ceiling system with visual impact, durability, and architectural flexibility.- — Timber-grain finishes
- — Suspended ceiling system
- — Group 1 fire rating
- — AS1530.1 non-combustibility
- — Sea salt and spray tested
Finishes
— Timber Grain
MX DuraDesign & Performance
Design — Suspended grid ceiling solution, designed for quick and ease of installation
Fire rating — Up to BAL 29 or Group 3 fire-rated timber species available (Group 1 if Fireshield coating is applied) and aluminium profiles are AS1530.1 non-combustible or Group 1 fire rated
Sustainability — Available in Green & Supergreen aluminium to reduce CO2 emission by 50-75% or a large range of sustainable timber species
Pre-finished coatings — Available in a range of standard colours
Application — Suitable for internal and out of weather applications only
Grid size — Softwood species are suitable for a grid size of up to 1m x 1m. However, Hardwood species are only suitable for up to 0.6m x 0.6m and a max batten depth of 140mm
Technical Downloads & Compliance
Installation & Care Guides
Revit & CAD Content
Revit
A Revit project file (.RVT) containing all available families and types, organised for easy browsing with 2D, 3D and data views included.
Profile Cross Sections
Accessories
Sustainability
100% Australian-manufactured profiles and coatings, Modinex now offers Green and SuperGreen aluminum. Green aluminum produces around 50% less CO2 emissions (8kg CO2e/kg AL), and SuperGreen produces 75% less CO2 emissions (4kg CO2e/kg AL).
Modinex is committed to Net Zero by 2050 and working actively on reducing Scope 1 and Scope 2 emissions.
Modinex’s aluminum profiles are ASI Certified with full Chain of Custody management. All aluminium profiles are 100% recyclable at the end of their life cycle.
Using responsible sources lower-carbon aluminum on your next project is the right choice for the environment.
Natural Timber Characteristics
Modinex products are manufactured from genuine solid timber and should be understood as a natural material, not a synthetic or manufactured finish.
Natural variation in colour, grain, texture, knots, figure, coating absorption and board-to-board appearance is inherent to timber and forms part of its character. These variations are expected and do not constitute a defect where they fall within the nominated grade, product specification and applicable Australian Standards.
As timber is a hygroscopic material, it will naturally respond to environmental conditions. Minor movement, checking, weathering and visual changes may occur over time and should be expected as part of normal in-service performance.
All Modinex timber products are supplied in accordance with the nominated species, profile, grade and relevant Australian Standards unless otherwise agreed in writing.
Learn more about timber grading, natural variation and performance
https://modinex.com.au/species.
